The OVRT-LIVE-MC-B2 is a multi-framerate ingest and playout client. The OVRT-LIVE-MC-B2 offers frame-accurate UHD, 3G, HD or SD ingest and playout fit for broadcast and post-production applications. Each Mediaclient is equipped with up to 6.6TB of usable local RAID 6 storage for ingest and playout. Customers also have the option to Ingest and playout to/from network attached storage. Content can be ingested is a variety of MPEG-2 and MPEG-4 formats.
The OVRT-LIVE-MC-B2 offers dynamically configurable UHD/3G/HD/SD-SDI ingest ports, along with the dedicated playback ports for confidence play back of ingested content (with a minimal delay). The Jog/Shuttle/Play ports also allow content to be reviewed as it's being ingested. Alternately, this output can be used as a general-purpose playout for any local or network-stored content at the native standard of that content. The OVRT-LIVE-MC-B2 also leverages a shared code base with the OVRT-LIVE-2U-B2 to offer a variety of audio/video/vanc processing capabilities. The shared code base also ensures maximum interoperability for ingested content destined for playout on the OVRT-LIVE-2U-B2.
Real-time control of the OVRT-LIVE-MC-B2 is supported via popular industry protocols over IP or individual RS-422 ports.
Features
Multiple I/O Support SDI (UHD/3G/HD/SD), IP Compressed (H.264/MPEG-2), IP Uncompressed (SMPTE ST 2110, SMPTE ST 2022-6)
Multiple Frame Rate Support 2160p/59.94, 2160p/50, 2160p/29.97, 2160p/25, 1080p/59.94, 1080p/50, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, 625i, 525i
Advanced Ancillary Data Processing 608/708 Captions, OP42/OP47 Subtitles, DVB Subtitles, AFD (SMPTE ST 2016), Timecode, SCTE 104, V-Chip/XDS
Advanced Video Processing
Up/Down/Cross Conversion, AFD-based scaling
Real-time, frame-accurate, broadcast-quality Audio/Video codecs
Low-latency Confidence Playback while recording
Low-latency Jog/Shuttle/Play while recording
Low-res Proxy creation
Real-time Record/Playback to/from local RAID6 storage and/or NAS
Wrapper formats
MXF, GXF, MPEG-4, MOV, TS
Codecs
MPEG-2, H.264, AVCI, IMX-30, IMX-50, XDCAM50, PRORES, XAVC, DNxHD, PCM, Dolby pass-through, low-res MPEG-4 or MPEG-DASH proxy
The OVRT-LIVE-MC-B2 offers dynamically configurable UHD/3G/HD/SD-SDI ingest ports, along with the dedicated playback ports for confidence play back of ingested content (with a minimal delay). The Jog/Shuttle/Play ports also allow content to be reviewed as it's being ingested. Alternately, this output can be used as a general-purpose playout for any local or network-stored content at the native standard of that content. The OVRT-LIVE-MC-B2 also leverages a shared code base with the OVRT-LIVE-2U-B2 to offer a variety of audio/video/vanc processing capabilities. The shared code base also ensures maximum interoperability for ingested content destined for playout on the OVRT-LIVE-2U-B2.
Real-time control of the OVRT-LIVE-MC-B2 is supported via popular industry protocols over IP or individual RS-422 ports.
Features
Multiple I/O Support SDI (UHD/3G/HD/SD), IP Compressed (H.264/MPEG-2), IP Uncompressed (SMPTE ST 2110, SMPTE ST 2022-6)
Multiple Frame Rate Support 2160p/59.94, 2160p/50, 2160p/29.97, 2160p/25, 1080p/59.94, 1080p/50, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, 625i, 525i
Advanced Ancillary Data Processing 608/708 Captions, OP42/OP47 Subtitles, DVB Subtitles, AFD (SMPTE ST 2016), Timecode, SCTE 104, V-Chip/XDS
Advanced Video Processing
Up/Down/Cross Conversion, AFD-based scaling
Real-time, frame-accurate, broadcast-quality Audio/Video codecs
Low-latency Confidence Playback while recording
Low-latency Jog/Shuttle/Play while recording
Low-res Proxy creation
Real-time Record/Playback to/from local RAID6 storage and/or NAS
Wrapper formats
MXF, GXF, MPEG-4, MOV, TS
Codecs
MPEG-2, H.264, AVCI, IMX-30, IMX-50, XDCAM50, PRORES, XAVC, DNxHD, PCM, Dolby pass-through, low-res MPEG-4 or MPEG-DASH proxy
